ENGAGE ATTEMPT REST TIME
(Only available if using Magnetic pickup and multiple engage attempts)
This timer dictates the duration that the module will wait between attempts to engage the
starter.
PICKUP SENSOR FAIL DELAY
(Only available if using Magnetic pickup without multiple engage attempts)
This is only used if magnetic pickup speed sensing is selected. When cranking, the module
must receive a speed signal within this time. If no signal is present the generator will be
shutdown and Loss of Speed Sensing alarm given.
(ENG.CRANK DISCN.PAGE) ENGINE CRANK DISCONNECT page
CRNK DISCN.ON GEN.F Crank Disconnect On Gen. Frequency
Hz 25.0 – 75.0 30.0
CRNK DISCN.ON MAG.P Crank Disconnect On Magnetic Pickup
RPM 500-6000 500
CRNK DISCN.ON GEN.V Crank Disconnect On Gen. Voltage
VAC (dis)60 – 600 300
CRNK DISC.ON CH.G.V Crank Disconnect On Charge Alt. Voltage
VDC (dis)6.0 – 30.0
dis
CRNK DISCN.ON OIL P Crank Disconnect On Oil Pressure
BAR (dis)1.0-90.0 dis
The parameters in this page are used for engine started signals. If any of the selected
signals appears, the unit assumes that the engine has started.
CRANK DISCONNECT ON GENERATOR FREQUENCY
If the generator frequency over than 30.0 Hz, the unit assumes that the engine has started
and the unit stop cranking.
CRANK DISCONNECT ON MAGNETIC PICKUP
If the generator speed over than 500 Rpm, the unit assumes that the engine has started and
the unit stop cranking.
CRANK DISCONNECT ON GENERATOR VOLTAGE
If the generator voltage over than 300 Vac, the unit assumes that the engine has started and
the unit stop cranking.
CRANK DISCONNECT ON CHARGE GEN. VOLTAGE
If the charge alternator voltage over than 6.1 Vdc, the unit assumes that the engine has
started and the unit stop cranking. Note: If the charge generator input (terminal #15) is
disconnect, this parameter selected as disabled (6.0 Vdc).
CRANK DISCONNECT ON OIL PRESSURE
If the oil pressure sender over than this value or the oil pressure digital input (terminal #18) is
not switched to -Battery, the unit assumes that the engine has started and the unit stop
cranking.
(GEN.SPED SETING PAGE) GENERATOR SPEED SETTINGS page
GEN.UNDER SPEED Generator Under Speed
RPM (dis)500 – 5000
500
GEN.UNDR SPED PRE-A Generator Under Speed Prealarm
RPM (dis) 500 – 5000
500
GEN.UNDR SP.PR-A.RT Generator Under Speed Prealarm Return
RPM 500 – 5000 500
GEN.OVER SPED PRE-A Generator Over Speed Prealarm
RPM (dis) 500 – 5000
500
GEN.OVER SP.PR-A.RT Generator Over Speed Prealarm Return
RPM 500 – 5000 500
GEN.OVER SP.SHUTDWN Generator Over Speed Shutdown
RPM (dis) 500 – 5000
500
The parameters in this page are used for the generator speed low and high alarms.
