‘gen open timer’ is initiated. Should the ‘Generator Closed Auxiliary’ input become in-active
the timer ‘gen open timer’ is cancelled. If the timer expires and the ‘Generator Closed
Auxiliary’ has not become in-active the module will issue a ‘generator failed to open’ alarm.
MAINS CLOSE TIMER
This is used to monitor the closure of the mains contactor or breaker. It will only operate if an
auxiliary input is configured as ‘Mains Closed Auxiliary’ and connected to the auxiliary on the
mains contactor or breaker. Once a mains closed signal is issued the ‘mains close timer’ is
initiated. Should the ‘Mains Closed Auxiliary’ input become active the timer the ‘mains close
timer’ is cancelled. If the timer expires and the ‘Mains Closed Auxiliary’ has not become
active the module will issue a ‘mains failed to close’ alarm.
MAINS OPEN TIMER
This is used to monitor the opening of the mains contactor or breaker. It will only operate if
an auxiliary input is configured as ‘Mains Closed Auxiliary’ and connected to the auxiliary on
the mains contactor or breaker. Once a mains open signal is issued the ‘mains open timer’ is
initiated. Should the ‘Mains Closed Auxiliary’ input become in-active the timer the ‘mains
open timer’ is cancelled. If the timer expires and the ‘Mains closed auxiliary’ has not become
in-active the module will issue a ‘mains failed to open’ alarm.
BREAKER CLOSE PULSE TIME
This is used to determine the duration of the Mains and Generator close signals. This timer is
only used if Pulsed outputs are configured to be used.
BREAKER OPEN PULSE TIME
This is used to determine the duration of the Mains and Generator close signals. This timer is
only used if Pulsed outputs are configured to be used.
TRANSFER TIME
This is used to allow for fixed duration transfer breaks when switching from mains to
generator and back. It can be used to ensure that the supply is removed from the load for
fixed period of time to allow pumps/motors to come to rest etc.
(LCD CONFIG.PAGE) LCD CONFIGURATION page
ERR.MESS SCROLL TIM
Scroll Time For Error Messages Sec 1 - 99 2
DIGITAL CONTRAST
Digital Contrast 0 – 15 7
BACKLIGHT ON/OFF
Backlight On/Off 0 - 1 0
AUTO SCROLL TIMER
Error messages are displayed eighth line of LCD Display. If more than one error condition is
present, each of them is displayed during time defined by Auto Scroll Timer parameter.
DIGITAL CONTRAST
It is used to change contrast of LCD Display.
BACKLIGHT ON/OFF
0- Backlight on. 1- Backlight off.
