Descriptions of All Connectors
ON/OFF Power switch button
PWR Connect with power adapter
1X Connect with Ethernet Cable to Switch Hub or PC
2X Connect with Ethernet Cable to Switch Hub or PC
3X Connect with Ethernet Cable to Switch Hub or PC
4X Connect with Ethernet Cable to Switch Hub or PC
DEFAULT Reset button
USB Connect with USB cable to PC
LINE Connect with phone cable
2.5 Connect Related Devices
1) Connect Router to LINE
Plug the provided RJ-11 phone cable into LINE port on the back panel of the router
and insert the other end into splitter or wall phone jack.
2) Connect Router to LAN
Plug RJ-45 Ethernet Cable into LAN port on the back panel of the router and insert
the other end of the Ethernet cable on your PC’s Ethernet port or switch / hub.
3) Connect Router to Power Adapter
Plug Power Adapter to PWR port on the back panel of the router and the other end
to a power outlet.
4) Press ON/OFF button to start the router
5) If you connect your router via USB cable, plug the provided USB cable into USB
port on the back panel of the router and insert the other end of the USB cable to PC.
Warning! Only use the power adapter provided in the package, otherwise it may cause
hardware damage.
9
