Encore ENDSL-A2+R2 User Manual

2. Hardware Installation
2.1 System Requirements
z Pentium III 266 MHz processor or higher
z 128 MB RAM minimum
z 20 MB of free disk space minimum
z RJ45 Ethernet Port
z USB Port
z CD-ROM drive
2.2 Package Contents
z ENDSL-A2+R2
z RJ-45 Ethernet cable
z RJ-11 Phone cable
z USB Cable
z Power Adapter
z Software driver CD
z Quick Installation Guide
2.3 Front Panel Indicators and Description
Front panel of ENDSL-A2+R2 has LED indicators to display router’s operating status.
One-Port ADSL Router Front Panel
○ ○ ○ ○ ○
ADSL DATA LAN USB PWR
Descriptions of LED status
7
ADSL
When connection with Internet (ADSL Connected) is established, this LED will light up.
When this LED is flashing: NO ADSL physical connection
DATA When router is transferring data between Internet and router, this LED will be flashing.
LAN
When connection 10/100MB with end user is established, this LED will light up. When
router is transferring data between router and end user, this LED will be flashing.
USB When an active USB cable is connected with router, this LED will light up.
PWR When an active power adapter is connected with router, this LED will light up.
