Cerabar PMC11, PMC21, PMP11, PMP21, PMP23 Technical data
Endress+Hauser 31
12 Technical data
12.1 Input
12.1.1 Measured variable
Measured process variable
• PMC11: gauge pressure
• PMP11: gauge pressure
• PMC21: gauge pressure or absolute pressure
• PMP21: gauge pressure or absolute pressure
• PMP23: gauge pressure or absolute pressure
Calculated process variable
Pressure
12.1.2 Measuring range
Ceramic process isolating diaphragm
Sensor Device Maximum
Sensor measuring range
Lowest
calibratable
span
1)
MWP OPL Factory settings
2)
Option
3)
lower (LRL) upper (URL)
[bar (psi)] [bar (psi)] [bar (psi)] [bar (psi)] [bar (psi)]
Devices for gauge pressure measurement
100 mbar (1.5 psi)
4)
PMC21 –0.1 (–1.5) +0.1 (+1.5) 0.02 (0.3) 2.7 (40.5) 4 (60) 0 to 100 mbar (0 to 1.5 psi) 1C
250 mbar (4 psi)
5)
PMC21 –0.25 (–4) +0.25 (+4) 0.05 (1) 3.3 (49.5) 5 (75) 0 to 250 mbar (0 to 4 psi) 1E
400 mbar (6 psi)
6)
PMC11
PMC21
–0.4 (–6) +0.4 (+6) 0.08 (1.2) 5.3 (79.5) 8 (120) 0 to 400 mbar (0 to 6 psi) 1F
1 bar (15 psi)
6)
PMC11
PMC21
–1 (–15) +1 (+15) 0.2 (3) 6.7 (100.5) 10 (150) 0 to 1 bar (0 to 15 psi) 1H
2 bar (30 psi)
6)
PMC11
PMC21
–1 (–15) +2 (+30) 0.4 (0.6) 12 (180) 18 (270) 0 to 2 bar (0 to 30 psi) 1K
4 bar (60 psi)
6)
PMC11
PMC21
–1 (–15) +4 (+60) 0.8 (1.2) 16.7 (250.5) 25 (375) 0 to 4 bar (0 to 60 psi) 1M
6 bar (90 psi)
6)
PMC11
PMC21
–1 (–15) +6 (+90) 2.4 (36) 26.7 (400.5) 40 (600) 0 to 6 bar (0 to 90 psi) 1N
10 bar (150 psi)
6)
PMC11
PMC21
–1 (–15) +10 (+150) 2 (30) 26.7 (400.5) 40 (600) 0 to 10 bar (0 to 150 psi) 1P
16 bar (240 psi)
6)
PMC11
PMC21
–1 (–15) +16 (+240) 6.4 (96) 40 (600) 60 (900) 0 to 16 bar (0 to 240 psi) 1Q
25 bar (375 psi)
6)
PMC11
PMC21
–1 (–15) +25 (+375) 10 (150) 40 (600) 60 (900) 0 to 25 bar (0 to 375 psi) 1R
40 bar (600 psi)
6)
PMC11
PMC21
–1 (–15) +40 (+600) 8 (120) 40 (600) 60 (900) 0 to 40 bar (0 to 600 psi) 1S
