Commissioning
29
"
Caution!
If the set up CompactFlash card is not removed, the measurement data will begin to be saved after
approx. 5 minutes. The set up data is still kept. Please change the CompactFlash card if the
measurement data is not meant to be saved onto this card.
"
Caution!
Correct and safe functioning is only guaranteed with genuine CompactFlash cards of the
manufacturer (see "Accessories", Section 8).
6.3.4 Set up direct at the unit (via unit keyboard)
•Press
F
. The main menu appears.
•With
V
or
W
select the desired chapter
• Confirm with
F
• Use the softkey
to call up the Help on the entry selected.
Key function in set up
Z
Cancel entries or return to previous screen.
UT
Moves cursor left or right.
VW
Moves bar up or down, changes parameter/sign.
F
: Enter key = selects the highlighted function, starts parameter change.
!
Note!
• Every parameter is modified via a dialog box.
• The altered settings only take effect once you return to normal operation by pressing
Z
several
times (confirm you accept changes with
F
). Until this time, the unit still works with the previous
data.
Procedure for unit configuration/set up:
Start
Basic settings (language, date/time, save cycle, CompactFlash, etc.)
Signal settings for the analog inputs (signal type, input range, etc.)
Signal settings for the digital inputs (function, designation, etc.)
Signal settings of the set points and alarm relays (if necessary)
Signal settings for the relays (operating mode, description, etc.)
Communication settings (USB/RS232/RS485/Ethernet)
End
