6.4.2 Setup - Signal Settings
Setup of the analog and digital inputs, mathematics function, set points, relays and display.
Procedure for the signal settings of the analog inputs:
Start
Set signal for analog input (current, voltage, resistance therm., thermocouple)
Set range for analog input (e.g. 0-20 mA for current)
Enter channel identifier
Select plot type
Enter unit/dimension
Enter number of digits after decimal point
Enter measuring range and zoom range
Enter damping/filter (if necessary)
Enter offset for start and end of measuring range
Set fault mode (e.g. in event of cable open circuit)
Do set points have to be defined? Yes
->
See Signal Settings -> Set Points
(see Page 46)
No
Select channel display for curve display, bar graph and digital display
End
