Commissioning
43
Setup - Signal Settings, submenu: Digital Inputs
Procedure for the signal settings of the digital inputs:
1. Start
2. Select the function of the digital channel
3. Control input 3. On/off event 3. Pulse counter 3. Operational time 3. Event + operation
time
4. Enter channel
identifier
4. Enter channel
identifier
4. Enter channel
identifier
4. Enter channel
identifier
4. Enter channel
identifier
5. Select action 5. Enter event text
for status change
from L->H
5. Enter unit/
dimension
5. Where necessary,
enter current
counter reading to
continue a total/
yearly counter
5. Enter event text
for status change
from L->H
6. End 6. Enter event text
for status change
from H->L
6. Select the number
of decimal places
6. Select display for
counter type (e.g.
daily counter)
6. Enter event text
for status change
from H->L
7. End 7. Enter pulse factor 7. End 7. Where necessary,
enter current
counter reading to
continue a total/
yearly counter
8. Where necessary,
enter current
counter reading to
continue a total/
yearly counter
8. Select display for
counter type (e.g.
daily counter)
9. Select display for
counter type (e.g.
daily counter)
9. End
10. End
