Accessories Liquisys M CPM223/253
102 Endress+Hauser
10.2 Connection accessories
CPK9 measuring cable
• For sensors with TOP68 plug-in head, for high-temperature and high-pressure
applications, IP 68
• Ordering acc. to product structure, see Technical Information (TI00118C/07/EN)
CPK1 measuring cable
• For pH/ORP electrodes with GSA plug-in head
• Ordering acc. to product structure, see Technical Information (TI00118C/07/EN)
CPK2 special measuring cable
• For pH/ORP electrodes with GSA plug-in head, with three sensor plugs
• Ordering acc. to product structure, see Technical Information (TI00118C/07/EN)
CPK12 special measuring cable
• For pH/ORP glass electrodes and ISFET sensors with TOP68 plug-in head
• Ordering acc. to product structure, see Technical Information (TI00118C/07/EN)
CYK10 Memosens data cable
• For digital sensors with Memosens technology
• Ordering according to product structure, see below
CYK81 measuring cable
• Non-terminated cable for extending the sensor cables (e.g. Memosens)
• 2x2 wires, twisted with shield and PVC sheath (2 x 2 x 0.5 mm
2
+ shield)
• Goods sold by meter, order no.: 51502543
Junction box VBM
• For cable extension with 10 terminals
• Cable entries: 2 x Pg 13.5 or 2 x NPT ½"
• Material: aluminum
• Ingress protection: IP 65 (i NEMA 4X)
•Order numbers:
– cable entries Pg 13.5: 50003987
– cable entries NPT ½": 51500177
Junction box VBA
• For cable extension of pH/ORP sensors
• 10 terminals, protection class: IP 65 (i NEMA 4X)
• Cable entries: 2 x Pg 13.5, 2 x Pg 16
• Material: polycarbonate
• Order no.: 50005276
Certificates
A Standard, non-Ex
G ATEX II 1G Ex ia IIC T6/T4/T3, FM/CSA IS/NI Cl I DIV 1&2 GP A-D
L LABS free, non-Ex
O FM IS/NI Cl I DIV 1&2 GP A-D
S CSA IS/NI Cl I DIV 1&2 GP A-D
T TIIS
V ATEX/NEPSI II 3G Ex nL IIC
Cable length
03 Cable length: 3 m (9.8 ft)
05 Cable length: 5m(16ft)
10 Cable length: 10 m (33 ft)
15 Cable length: 15 m (49 ft)
20 Cable length: 20 m (66 ft)
25 Cable length: 25 m (82 ft)
88 ... m length
89 ... ft length
Ready-made
1 Wire terminals
2M12 plug
CYK10- complete order code
