Liquisys M CPM223/253 Repair
Endress+Hauser 97
Item Kit description Name Function/contents Order number
10 Power unit LSGA 100 / 115 / 230 V AC 51500317
20 Power unit LSGD 24 V AC + DC 51500318
30 Jumper Part of power unit, item 10
40 Central module LSCH-S1 1 current output 51501081
40 Central module LSCH-S2 2 current outputs 51501082
40 Central module LSCH-H1 1 current output + HART 51501083
40 Central module LSCH-H2 2 current outputs + HART 51501084
40 Central module LSCP PROFIBUS PA/no current output 51501085
40 Central module LSCP PROFIBUS DP/no current output 51502503
40 Kit CPM2x3 Central module
PROFIBUS DP
LSCP-DP Central module PROFIBUS DP
Relay module + 2 relays
Current input and terminals
valid of: hardware version 2.10
71134724
230 pH/mV transmitter MKP1 pH/mV + temperature input
Glass electrode
51501080
230 pH/mV transmitter MKP2 pH/mV + temperature input ISFET
sensor
51507096
230 pH/mV transmitter MKP3 pH/mV + temperature input
Glass electrode
software versions 2.55 HART,
2.33 PROFIBUS or newer
51518244
230 Memosens-transmitter MKD1 digital input 51514966
290 Relay module LSR1-2 2 relays 51500320
290 Relay module LSR2-2i 2 relays + current input 4 to 20 mA 51504304
290 Kit CxM2x3 Relay module
PROFIBUS DP
LSR2-DP Relay module + 2 relays
Current input and terminals DP
valid of: hardware version 2.10
71134732
300 Relay module LSR1-4 4 relays 51500321
300 Relay module LSR2-4i 4 relays + current input 4 to 20 mA 51504305
310, 320 Ribbon cable lines 2 ribbon cable lines 51501074
340, 330,
450
Inner housing fittings Docking module, empty electronics
box, small parts
51501073
450a,
450c
Torx screws K4x10 Part of inner housing fittings
450b Torx screw for central module Part of inner housing fittings
410, 420,
370, 430,
460
Housing cover Display cover, connection
compartment cover, front membrane,
hinges, cover screws
51501068
460a,
460b
Cover screws Part of housing cover
430 Hinges 2 pairs of hinges 51501069
400, 480 Housing base Base, threaded joints 51501072
470 Terminal strip Terminal strip for connection to
mains
51501079
490 PE rail PE connection rail for screen
grounding for IS version
51501087
999 pH/mV terminal module ph/mV terminal + screening plate 51501071
A Electronics box with relay
module LSR1-x (bottom) and
power unit LSGA/LSGD (top)
