Troubleshooting RIA45
42 Endress+Hauser
Item no. Designation
10 Terminals 4-pin for analog input
Terminal, analog input non-Ex (terminals x1, x2, x3, x4 and x5, x6, x7, x8)
Terminal, analog input Ex, blue at top (terminals x1, x2, x3, x4)
Terminal, analog input Ex, blue at bottom (terminals x5, x6, x7, x8)
11 Terminal for analog output 2 (O25, O26)
12 Terminal for analog output 1 and status output (DI 11, DI12, O15)
13 Terminal. relay output (R12, R11, R13 and R22, R21, R23)
14 Threaded rod for casing securing frame
w/o no. Sealing ring housing/panel (only devices before 10/2010)
