Technical data RIA45
48 Endress+Hauser
13.4 Performance characteristics
13.4.1 Reference operating conditions
Power supply: 230 V
AC
, 50/60 Hz
Ambient temperature: 25 °C (77 °F) ± 5 °C (9 °F)
Humidity: 20 %...60 % rel. humidity
13.4.2 Maximum measured error
Universal input:
Accuracy Input: Range: Maximum measured error of
measuring range (oMR):
Current 0 to 20 mA, 0 to 5 mA, 4 to 20 mA; Overrange: up to
22 mA
±0.05%
Voltage ≥ 1 V 0 to 10 V, 2 to 10 V, 0 to 5 V, 1 to 5 V, 0 to 1 V, ±1 V,
±10 V, ±30 V
±0.1%
Voltage < 1 V ±100 mV ±0.05%
Resistance measurement 30 to 3 000 Ω 4-wire: ± (0.10% oMR + 0.8 Ω)
3-wire: ± (0.10% oMR + 1.6 Ω)
2-wire: ± (0.10% oMR + 3 Ω)
RTD Pt100, –200 to 850 °C (–328 to 1 562 °F) (IEC60751,
α=0.00385)
Pt100, –200 to 850 °C (–328 to 1 562 °F) (JIS1604,
w=1.391)
Pt100, –200 to 649 °C (–328 to 1 200 °F) (GOST,
α=0.003916)
Pt500, –200 to 850 °C (–328 to 1 562 °F) (IEC60751,
α=0.00385)
Pt1000, –200 to 600 °C (–328 to 1 112 °F) (IEC60751,
α=0.00385)
4-wire: ± (0.10% oMR + 0.3 K (0.54 °F))
3-wire: ± (0.10% oMR + 0.8 K (1.44 °F))
2-wire: ± (0.10% oMR + 1.5 K (2.7 °F))
Cu100, –200 to 200 °C (–328 to 392 °F) (GOST,
w=1.428)
Cu50, –200 to 200 °C (–328 to 392 °F) (GOST, w=1.428)
Pt50, –200 to 1 100 °C (–328 to 2 012 °F) (GOST,
w=1.391)
Pt46, –200 to 850 °C (–328 to 1 562 °F) (GOST,
w=1.391)
Ni100, –60 to 250 °C (–76 to 482 °F) (DIN43760,
α=0.00617)
Ni1000, –60 to 250 °C (–76 to 482 °F) (DIN43760,
α=0.00617)
4-wire: ± (0.10% oMR + 0.3 K (0.54 °F))
3-wire: ± (0.10% oMR + 0.8 K (1.44 °F))
2-wire: ± (0.10% oMR + 1.5 K (2.7 °F))
Cu53, –50 to 200 °C (–58 to 392 °F) (GOST, w=1.426) 4-wire: ± (0.10% oMR + 0.3 K (0.54 °F))
3-wire: ± (0.10% oMR + 0.8 K (1.44 °F))
2-wire: ± (0.10% oMR + 1.5 K (2.7 °F))
Thermocouples Typ J (Fe-CuNi), –210 to 1 200 °C (–346 to 2 192 °F)
(IEC60584)
± (0.10% oMR +0.5 K (0.9 °F))
from –100 °C (–148 °F)
Typ K (NiCr-Ni), –200 to 1 372 °C (–328 to 2 502 °F)
(IEC60584)
± (0.10% oMR +0.5 K (0.9 °F))
from –130 °C (–202 °F)
Typ T (Cu-CuNi), –270 to 400 °C (–454 to 752 °F)
(IEC60584)
± (0.10% oMR +0.5 K (0.9 °F))
from –200 °C (–328 °F)
Typ N (NiCrSi-NiSi), –270 to 1 300 °C (–454 to 2 372 °F)
(IEC60584)
± (0.10% oMR +0.5 K (0.9 °F))
from –100 °C (–148 °F)
Typ L (Fe-CuNi), –200 to 900 °C (–328 to 1 652 °F)
(DIN43710, GOST)
± (0.10% oMR +0.5 K (0.9 °F))
from –100 °C (–148 °F)
Typ D (W3Re/W25Re), 0 to 2 495 °C (32 to 4 523 °F)
(ASTME998)
± (0.15% oMR +1.5 K (2.7 °F))
from 500 °C (932 °F)
