RMS 621 6 Commissioning
Endress+Hauser 35
gal/bbl 31,5 (US), 42,0 (US), 55,0
(US), 36,0 (Imp), 42,0
(Imp), user def.
31,0
Definition of the value of the used gal/bbl.
US: US-Standard
Imp: XX-Standard
user defined: Freely selectable calculation factor allowed.
Format 9; 9.9; 9.99; 9.999 Number of decimal points
Meter coeff. Pulse value
k factor
Selection of the meter coefficient type.
pulse value (unit/pulse)
k factor (pulses/unit)
Pulse unit l, hl, ft
3
, ... Measurement unit for the pulse factor
Pulse value 0.001 to 99999 Set up what volume flow (in dm
3
or litre) is equal to one pulse
of the flowmeter.
!
Note!
Only available on pulse signal mode.
Signal damping 0 to 99 s Time constant of a 1st order low pass filter for the input signal.
This function is used to avoid display fluctuations on high
fluctuating input signals.
!
Note!
Only selectable for the 0/4 to 20 mA signal.
K factor unit pulses/dm
3
pulses/ft
3
Measurement unit for the K factor
K factor 0.001 to 9999.9 Input of the sensor pulse factor for the vortex sensor. This
value can be found on the meter.
!
Note!
On vortex sensors using pulse signals the inverse of the K
factor (in pulses/dm
3
) is entered as the pulse factor (only
required for PFM signals)
Diff. press. unit mbar
in/H
2
O
Differential pressure engineering units
Start value 0.0000 to 999999 Start value for the flow (differential pressure) at 0 or. 4 mA.
!
Note!
Only selectable for the 0/4 to 20 mA signal.
End value 0.0000 to 999999 End value for the flow (differential pressure) value at 20 mA.
!
Note!
Only selectable for the 0/4 to 20 mA signal.
Offset -9999.99 to 9999.99 Moves the zero point on the sensor curve. this function helps
by fine adjustment of the sensor.
!
Note!
Only selectable for the 0/4 to 20 mA signal.
Flow Cut-off. 0.00.1 to 99.90.0 %
4.0 %
Under a certain preset value the flow is no longer recorded or
is set to 0. The creapage value is set as a %age of the flow
measurement full scale deflection or as a fixed flow value (e.g.
in m3/h) dependent on the type of flow meter used.
Correction Yes
No
Possibility to correct the flow measurement reading. If "Yes" is
selected the sensor used curve can be defined in the sol called
correction table and there is also a possibility to compensate
the temperature influence on the flow measuring device (see
"Thermal coefficient").
Therm. coefficient 0.00 to 999.99 * 10
-6
Correction factor used to compensate the temperature
influence on the flow measurement device. This factor is often
identified on the meter legend plate in. for example, turbulent
flow measurement. If the value for the expansion coefficient is
not known or the flow measurement device compensates this
automatically then a "0" must be entered in this address.
!
Note!
Hint! Only active when the correction address is active. Not
selectable for differential pressure devices!
Function (Menu
address)
Parameter set-up Description
