6 Commissioning RMS 621
36 Endress+Hauser
Correction table Current/flow
Frequency/K factor
Flow/factor
Should the flow curve of the flow measurement device deviate
from the ideal (linear or squared) this can be compensated for
by set up of the correction table. The parameters in the table
are dependent on the selected flow measurement device.
Analogue signal
Up to 15 pairs of values (current/flow)
Pulse signal
Up to 15 pairs of values (frequency/k factor or
frequency/pulse value)
Differential pressure
Up to 10 pairs of values (flow/factor)
For details see ’Correction tables’ in the appendix.
Pipe data Pipe internal diameter
Diameter ratio
Input of the pipe line internal diameter.
Input of the diameter ratio (d/D = ß) of the differential
pressure device. This value will be supplied by the
manufacturer of the differential pressure device.
!
Note!
Addresses are only active on differential pressure devices. On
standard pressure devices only enter the pipe internal
diameter.
Sums l, hl, dm
3
, m
3
Set up the sum counter
Splitting range Splitting range or automatic measurement range change over
for differential pressure devices.
!
Note!
Only selectable for differential pressure
measurements.
For details see ’Splitting range’ in the appendix.
Term. range 1 A-10; A-110; B-112;
B-113; C-112; C-113; D-
112; D-113
Terminals for connection to the differential pressure range with
the smallest measurement range
Term. range 2 A-10; A-110; B-112;
B-113; C-112; C-113; D-
112; D-113
Terminals for connection to the differential pressure range with
the second largest measurement range
Term. range 3 A-10; A-110; B-112;
B-113; C-112; C-113; D-
112; D-113
Terminals for connection to the differential pressure range with
the largest measurement range
Correction table Yes
No
See above correction table
Range start 1 (2, 3) 0.0000 to 999999 Start value for differential pressure at 0 or 4 mA, defined for
the pressure transmitter in range 1 (2,3)
!
Note!
Only active if a terminal has been allocated.
Range end 1 (2, 3) 0.0000 to 999999 End value for differential pressure at 20 mA, defined for the
pressure transmitter in range 1 (2,3)
!
Note!
Only active if a terminal has been allocated.
Average flow Not used
2 sensors
3 sensors
Average value calculation from a number of flow
signals
(For details see ’Average calculation’ in the appendix)
Function (Menu
address)
Parameter set-up Description
