Introduction
Hardware Installation and Maintenance Manual 1
–15
Fuses
Fuses are located on the electronics control board, as shown in Figure 1–6 on
page 1–11, Figure 1–7 on page 1–12, Figure 1–8 on page 1–13 and Figure 1–9
on page 1–14. The spare part kits for fuses are shown in Table 1–1 below and
Table 1–2 on page 1–16
.
If you need to replace a fuse, use only the same type and rating
of fuse as the original. Refer also to specifications listed in
Table 1–1 below and Table 1–2 on page 1–16.
Select the replacement solenoid fuse (F2) based on the number
of solenoids installed on the analyzer.
Table 1–1 Fuse specifications (Analyzer A)
Drawing Reference Voltage Description Rating
Figure 1–6 F1 120 VAC 1 Solenoid, Miniature Fuse,
5 x 20 mm, Time Delay
250 VAC
0.25 A
2 Solenoids, Miniature Fuse,
5 x 20 mm, Time Delay
250 VAC
0.4 A
3 Solenoids, Miniature Fuse,
5 x 20 mm, Time Delay
250 VAC
0.4 A
F2 Miniature Fuse, 5 x 20 mm,
Time Delay
250 VAC
0.8 A
F1 240 VAC 1 Solenoid, Miniature Fuse,
5 x 20 mm, Time Delay
250 VAC
0.125 A
2 Solenoids, Miniature Fuse,
5 x 20 mm, Time Delay
250 VAC
0.25 A
3 Solenoids, Miniature Fuse,
5 x 20 mm, Time Delay
250 VAC
0.40 A
F2 Miniature Fuse, 5 x 20 mm,
Time Delay
250 VAC
0.8 A
Figure 1–7 F1 24 VDC 1 Solenoid, Miniature Fuse,
5 x 20 mm, Time Delay
250 VAC
0.63 A
2 Solenoid, Miniature Fuse,
5 x 20 mm, Time Delay
250 VAC
1.25 A
3 Solenoid, Miniature Fuse,
5 x 20 mm, Time Delay
250 VAC
2.0 A
F3 Miniature Fuse, 5 x 20 mm,
Time Delay
250 VAC
1.6 A
