2-Pack Analyzer System
3–18 4900002256 rev. B 4-13-21
Tocalibratetheanalogoutput(AnalyzerA)
1. Connect a calibrator and digital multi-meter into the circuit.
2. On the analyzer keypad, press #2 (Mode 2), the password (3142)
and *.
3. Continue pressing the * key until the 4-20 mA Test parameter
displays.
4. Enter the desired percentage of full scale and press *.
a. Set 4-20 mA Test = 0; this displays the 4 mA on the AO circuit
when #5 (Mode 5) is pressed.
b. Set 4-20 mA Test = 50; this displays the 12 mA on the AO circuit
when #5 is pressed.
c. Set 4-20 mA Test = 100; this displays the 20 mA on the AO
circuit when #5 is pressed.
5. Press # and 1 to return to Normal Mode.
Tocalibratetheanalogoutput(AnalyzerB)
1. Connect a calibrator and digital multi-meter into the circuit.
2. On the analyzer keypad, press #2 (Mode 2), the password (3142)
and *.
3. Continue pressing the * key until the 4-20 mA % Test parameter
displays.
4. Set the current loop output to 20 mA by setting to 100.
5. Adjust the receiver calibration control to read the appropriate value.
the current loop output of 20 mA corresponds to the concentration
value set by the 20 mA Value parameter.
<SET PARAMETER MODE>
AO 4-20 mA Test
0.00000
Enter a value (%)
<SET PARAMETER MODE>
4-20 mA % Test
101
Enter a % (101=Off)
