2-Pack Analyzer System
3–10 4900002256 rev. B 4-13-21
3. Run conduit from the power distribution panel to the conduit hub on
the lower right side of the heated enclosure labeled for power input.
Refer to "Application of conduit lubricant".
4. Pull the green ground, brown/white neutral and black hot wires (#14
AWG minimum) into the power terminal box inside the enclosure.
5. Strip back the jacket and/or insulation of the wires just enough to
connect to the power terminal block.
6. Connect the green wire (ground) to terminal 4, the brown/white wire
(neutral) to terminal 5 and the black wire (hot) to terminal 6 as
shown in Figure 3–4 on page 3–9.
7. Connect the ground wire to the ground terminal marked “G” or .
8. Close the power terminal box and latch the heated enclosure door.
Applicationofconduitlubricant
To ensure proper installation, SpectraSensors recommends using STL8 screw
thread lubricant or equivalent on all conduit screw thread and its taped
opening.
STL8 Screw Thread Lubricant is a lithium based, anti-galling substance with
excellent adhesion that maintains rain-tightness and grounding continuity
between conduit fittings. This lubricant has proven very effective between parts
made of dissimilar metals, and is stable in temperatures from -29
C to 149 C
(-20
F to 300F).
Conduit seals should be used where appropriate in compliance
with local regulations.
Because the breaker in the power distribution panel or switch will
be the primary means of disconnecting the power from the
analyzer, the power distribution panel or switch should be located
in close proximity to the equipment and within easy reach of the
operator or within 10 feet of the analyzer.
An approved switch or circuit breaker rated for 15 amps should be
used and clearly marked as the disconnecting device for the
analyzer.
Do not use this lubricant on exposed current-carrying parts.
