SS2100i-1 Analyzer
2–2 4900002260 rev. B 12-20-17
Instructional Symbols
Analyzer Technical Specifications
For each model of the SS2100i-1 analyzer, a set of technical specifications are
provided that outline recommended equipment settings and ratings. This
information is included in the Hardware Manual of each document package
provided with an analyzer.
Peripheral Devices
For systems equipped with peripheral devices, e.g., probe assemblies, the
documentation indicates that only devices that meet with the manufacturer’s
specifications may be used.
Maximum voltage and current specifications for fuses.
PROTECTIVE EARTH GROUND - Symbol indicates the
connection point of the ground wire from the main power source.
General notes and important information concerning the
installation and operation of the analyzer.
Failure to follow all directions may result in damage or
malfunction of the analyzer.
Failure to follow all directions or substitution of components may
result in explosion.
Failure to follow all directions may result in fire.
INVISIBLE LASER RADIATION - Avoid exposure to beam.
Class 3b Radiation Product. Refer servicing to the manufacturer-
qualified personnel.
