SS2100i-1 Analyzer
4–4 4900002260 rev. B 12-20-17
Exd Accessory Conditions of Use
All accessories listed in Table 4–2 shall comply with the latest IEC/EN 60079-0
and IEC/EN 60079-1 in addition to the following conditions:
Table 4-1 SS2100i-1 Analyzer Specifications (Continued)
Physical Specifications
Electronics Enclosure
IP66 copper-free aluminum with weather-resistant poly-
urethane powder coating, 80-120 micron thickness
Size
1
1. Dimensions are for analyzer only. Consult system drawings for analyzers with sample
conditioning systems.
670 mm H 489 mm W 377 mm D
(26.38” H 44.17”
W 9.76” D)
Weight
1
Approximately 86 Kg (190 lbs)
Sample Cell Construction 316L series polished stainless steel - Standard
Number of Sample Cells 1 per analyzer
Area Classification
Analyzer (Electronics and Laser)
CE, ATEX and IECEx:
II 2 G, Ex db IIB+H2 T4 GB;
LCIE 11 ATEX 3071X
2
, IECEx LCI 11.0057X
2
;
Directive 2014/34/EU
2. Including an “X” after the certificate number indicates that the product is subject to the
Special Conditions of Use specified in the schedule to this certificate. Refer to the Spe-
cial Conditions of Use under the relevant certification prior to installation or use.
Table 4–2 Exd accessory conditions of use
Accessory
Type
Rating Notes
Stopper Plug Exd, Zone 1 1. Stopping plugs shall be assembled in such a way
that their protrusion from an associated enclo-
sure is not increased.
2. Installer must ensure the stopping plug ingress
protection matches the ingress protection rating
of the associated enclosure, IP66.
Reducer/Adapter Exd, Zone 1 1. Adapter/reducers shall be assembled in such a
way that their protrusion from an associated
enclosure is not increased.
2. Installer must ensure the stopping plug ingress
matches the ingress protection of the rating of
the associated enclosure, IP66.
3. For direct entry Exd applications, only one
adapter/reducer shall be used per cable entry.
4. The female connection thread of a Thread Con-
version Adapter shall “step” not more than two
“size” up in the case of a thread gender change.
