Safety Manual 5–1
5 - MAINTENANCE AND SERVICE
This chapter provides safety information related to maintenance and service of
the SS2100i-1 analyzer. Refer to Figure 5–1 for a view of the SS2100i-1
analyzer configuration.
The SS2100i-1 analyzer supports two levels inside the analyzer enclosure. The
top level contains the electronics assembly, and the bottom level is the
measurement cell assembly. Refer to Figure 5–2 for an illustration of the top-
level electronics assembly components. Figure 5–3 provides an overview of
components included on a 8/28-m sample cell panel. While the analyzer cell
size may vary, the components remain the same.
ANALYZER ENCLOSURE
Figure 5–1 Analyzer component overview
SAMPLE CELL PANEL
ASSEMBLY
ELECTRONICS PANEL
ASSEMBLY
