Endress+Hauser SpectraSensors SS2100i-1 Safety Manual

SS2100i-1 analyzer
5–2 4900002260 rev. B 12-20-17
Figure 5–2 Components on electronics panel
assembly (Upper level)
4-20mA AO
BOARD
4-20mA AI
BOARD
FUSE (F3)
HIGH TEMP. LIMIT
THERMOSTAT
SET @ 70C
ANALYZER
POWER SUPPLY
RELAYS
AC LINE FILTER
FUSES (F4-F10)
MAIN CIRCUIT
BREAKER
GROUND
BUS BAR
TERMINAL
BLOCKS
GROUND
TERMINAL
BLOCKS
AUXILIARY
POWER SUPPLY
TEMPERATURE
CONTROL BOARD
ARM9 CONTROL
ELECTRONICS
RS-232 TO
RS-485
CONVERTER
