Safety Manual 3–1
3 - EQUIPMENT INSTALLATION
The information in this chapter is related to safety during the equipment
installation.
Lifting/Carrying the Analyzer
Before removing from the crate, move the analyzer as close as possible to the
final installation location. Due to the analyzer’s size and weight (approximately
86 Kg (190 lbs) without sample conditioning system), SpectraSensors
recommends the use of a forklift, pallet jack, etc. to lift and/or move the
analyzer.
Mounting the Analyzer
Refer to the layout diagrams provided with the purchased SS2100i-1 analyzer
for detailed mounting dimensions.
When an “X” is included after the certificate number, it indicates that the
product is subject to the Special Conditions of Use specified in the
schedule to this certificate. Refer to
Table 4-1 on page 4–3 for the
certification listings. The entries into the analyzer enclosure can be
equipped with certified accessories (e.g., blanking element,
breather/drainer, reducer, etc.) according to the intended use of the
product.
Ensure all equipment used for lifting/moving the analyzer is rated
for the weight load.
SpectraSensors analyzers are designed for operation within the
specified ambient temperature range. Intense sun exposure in
some areas may cause the analyzer temperature to exceed the
maximum.
When mounting the analyzer, be sure to position the instrument
so that it is not difficult to operate adjacent devices. Allow three
feet (1 meter) of room in front of the analyzer and any switches.
Bolts or screws used for wall-mounting the SS2100i-1 must be
able to support four times the weight of the instrument
(approximately [86 kg] 190 lbs without sample conditioning
system).
