Endress+Hauser SpectraSensors SS2100i-1 Safety Manual

Equipment Operation
Safety Manual 4
–3
System Specifications
Table 4-1 SS2100i-1 analyzer specifications
Performance
Concentration See analyzer calibration report
Repeatability See analyzer calibration report
Measurement Time
1
1. Application dependent.
Typically less than 20 seconds
Application Data
Environmental Temperature
Range
–20C to 50C (–4F to 122F) - Standard
–10C to 60C (14F to 140F) - Optional
Heated Enclosure Temperature
50 C - Standard
60 C - Optional
Environmental Relative
Humidity
5% to 95%, Non-condensing
Altitude Up to 2000 m
Sample Cell Operating Pressure
Typically 800-1200 mbar - Standard
950-1700 mbar - Optional
Pressure to Cell 70 kPaG (10 PSIG) max to spectrometer cell
Sample Flow Rate
0.5-4 SLPM (0.02-0.1 SCFM)
1
Contaminant Sensitivity
None for gas phase glycol, methanol, amines, or mercap-
tans
Electrical & Communications
Input Power, Maximum
2
2. Supply voltage not to exceed 10% of nominal. Transient over-voltages according to
Overvoltage category II.
120 or 240 VAC 10%, 50-60 Hz standard; ~300W
1
Communications
Analog: Isolated Analog channels, 1200 ohms @
24 VDC max
Outputs: Qty (2) 4-20 mA (measurement value)
Input: Qty (1) 4-20 mA (pipeline pressure)
1
Serial: Ethernet and RS-485 half-duplex - Standard
Digital Signals
Outputs: (5); Hi/Lo Alarm, General Fault, Validation Fail
1
,
Validation 1 Active
1
, Validation 2 Active
1
Inputs: (2); Flow Alarm
1
, Validation Request
1
Protocol Modbus Gould RTU, Daniel RTU or ASCII
Diagnostic Value Examples
Detector Power (Optics Health), Spectrum Reference
Comparison and Peak Tracking (Spectrum Quality), Cell
Pressure and Temperature (Overall System Health)
LCD Display
Concentration, Cell Pressure, Cell Temperature
and Diagnostics
