Maintenance and Service
Safety Manual 5
–3
Figure 5–3 Components on sample cell panel
assembly (8/28-m sample cell) (Lower level)
PRESSURE
SENSOR
MEASUREMENT
CELL
THERMISTOR
ASSEMBLY
TRANSITION
PLATE
THERMISTOR
HEATER
FAN
TEMPERATURE
CONTROLLER
AC TERMINAL
BLOCK FOR HEATER
SOLID-STATE
RELAY
