S o n o m a U s e r M a n u a l
58
C H A P T E R S E V E N
59
S o n o m a U s e r M a n u a l
H T T P S I N T E R F A C E
Page Descriptions
Home: Overall Status Page
Data elds for this page are described below.
Overall Status
Model Sonoma D12
Serial Number Serial number of the Sonoma D12. This eld will not be shown for units
shipped before August 2015.
UTC Time, The current UTC date and time is shown. This date will show year 1980 if
UTC Date the time has not yet been acquired.
Receiver This is the locked status of the CDMA Subsystem/Receiver as follows:
WRM: Warmup period for units with oscillator upgrades.
ACQ: Acquiring. Searching for a signal.
LKG: Locking to the CDMA Signal.
LKD: Locked. Fully synchronized to signal.
Stratum The NTP stratum eld has these possible values:
Stratum 1: The server is fully synchronized and accurate.
Stratum 2: The server is synchronized to a Stratum 1 server.
Stratum x: The server is synchronized to a Stratum x-1 server.
Stratum 16: The server is unsynchronized. NTP clients will not use a
Stratum 16 server.
System Status This eld indicates whether a system fault exists. Possible values are OK and
FAULT. If it shows FAULT then go to the Faults Page to see which particular
fault is the problem.
CPU Statistics
CPU temperature, free memory and load average are all shown.
Home: Front Panel Page
All settings related to the front-panel keypad and display are shown on this page.
Front-Panel Keypad and Display Conguration
Hour Display This eld denes whether the front-panel display shows time in 12 hours
Mode (AM/PM) or 24 hours. It can only be changed via the front-panel keypad/
display. Navigate to Clock Menu > Hour_Mode.
Keypad Lockout Changing the settings for the Keypad Lockout is done using console port
commands: lockoutkp and unlockkp.
Screen Saver This setting can only be changed via the front-panel keypad. After a period of
no use, screensaver mode will change the display intensity to half of its
intensity setting.
