9.1.3 Factory ranges and default values
Table J lists the rectifier settings, ranges, and default values. Changes are made through the controller interface.
Table J — Rectifier factory ranges and defaults
Setting Range (minimum to maximum) Default
Float (FL) Voltage 48 to 58 V 54 V
Equalize (EQ) Voltage 50 to 58 V 55 V
Battery Test (BT) Voltage 44 to 52 V 46 V
Over Voltage Protection (OVP)¹ 59 V 57 V
Current Limit (CL) 23 to 100% 100%
Power Limit (PL) 0 to 100% 100%
Module Start Delay 0 to 250 s 1 s
System Start Delay 0 to 600 s 0 s
Low Voltage Alarm (LVA) 42 to 52 V 44 V
High Voltage Alarm (HVA) 52 to 59 V 55.5 V
EQ Timeout 1 to 2399 h 30 h
BT Timeout 1 to 250 h 8 h
Softstart Ramp-rate Normal/Fast Normal
CL/PL Alarm Enable/Disable Enable
Remote Shutdown Enable/Disable Enable
Ramp Test Enable/Disable Enable
¹ The OVP cannot be set below the present system. FL, EQ, BT voltage setting or the safe mode voltage of
51.4 V.
