Enterasys 08G20G2-08P - Figure 2-22 08 A-RPS-150 P RPS Cable and AC Power Cord Connections

Installing and Connecting a Redundant Power System
2-28 Installation
Figure 2-22 08A-RPS-150P RPS Cable and AC Power Cord Connections
4. If the switch itself is not plugged into power, the front panel RPS LED indicator will show that
a redundant power supply is now in operation.
.
This completes the installation.
1 800-Series switch 4 800-Series switch redundant power supply
connector
2 RPS cable (1 meter long) 5 AC power cord (type varies depending on country)
3 08A-RPS-150P redundant power supply
connector
6 AC power outlet with ground connection
(type varies depending on country)
Note: No change in switch device configuration is necessary for this installation.
