Redundant Power Supply Specifications
A-6 Specifications
Redundant Power Supply Specifications
STK-RPS-150CH2 Chassis Specifications
Table A-2 provides the physical specifications for the STK-RPS-150CH2.
STK-RPS-150CH8 Chassis Specifications
Table A-3 provides the physical specifications for the STK-RPS-150CH8.
Switching Capacity • 08H20G4-24 - 12.8 Gbps
• 08H20G4-24P - 12.8 Gbps
• 08H20G4-48 - 17.6 Gbps
• 08H20G4-48P - 17.6 Gbps
• 08G20G2-08 - 20 Gbps
• 08G20G2-08P - 20 Gbps
• 08G20G4-24 - 56 Gbps
• 08G20G4-24P - 56 Gbps
• 08G20G4-48 - 104 Gbps
• 08G20G4-48P - 104 Gbps
Forwarding Mode Store and Forward
Priority Queues 8 Priority Queues per port
MAC Address Table 16K MAC Address Table
Packet Buffer Memory 1.5 MB buffer memory per device
Jumbo Frames Up to 12 KB
Power-over-Ethernet Supports IEEE 802.3af PoE and IEEE 802.3at PoE+
(Only for the 08H20G4-24P, 08H20G4-48P, 08G20G2-08P,
08G20G4-24P, and 08G20G4-48P)
Table A-2 STK-RPS-150CH2 Specifications
Item Specification
Power supply slots Two slots for optional 08A-RPS-150P power supplies
Dimensions without mounting brackets 5.5 H x 48.2 W x 18.0D (cm)
2.2 H x 19.0 W x 7.0 D (in.)
Net Weight (Unit Only)
Gross Weight (Packaged Unit)
0.95 kg (2.09 lb)
1.60 kg (3.52 lb)
Table A-3 STK-RPS-150CH8 Specifications
Item Specification
Power supply slots Eight slots for optional 08A-RPS-150P power supplies
Dimensions without mounting brackets 22.26 H x 44.0 W x 26.4 D (cm)
8.77 H x 17.3 W x 10.4 D (in.)
Net Weight (Unit Only)
Gross Weight (Packaged Unit)
5.27 kg (11.6 lb)
6.5 kg (14.3 lb)
