Redundant Power Supply Specifications
A-8 Specifications
08A-RPS-24 Specifications
Table A-6 provides the specifications for the 08A-RPS-24.
MTBF 589,644 Hours at 25°C (77°F)
Environmental
Operating Temperature 0°C to 65°C (32°F to 149°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Operating Relative Humidity 5% to 95% RH
Table A-5 08A-RPS-500 Specifications (continued)
Item Specification
Table A-6 08A-RPS-24 Specifications
Item Specification
Electrical
AC Input Frequency Range
AC Input Voltage Range
Output Voltage
Output Current
Maximum Output Power
47–63 Hz
90–264 Vac
12 Vdc
0.0 A min., 3.0 A max.
36 Watt
Physical
Dimensions 3 H x 4.9 W x 11.5 D (cm)
1.2 H x 1.9 W x 4.5 D (in.)
Net Weight (Unit Only)
Gross Weight (Packaged Unit)
0.175 kg (0.4 lb)
0.675 kg (1.50 lb)
MTBF 50,000 Hours
Environmental
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 85°C (-4°F to 185°F)
Operating Relative Humidity 10% to 80% RH
