Entes MPR-45 - THD and Harmonics Screens

21
BUTTON NAME
DISPLAYED MEASUREMENT SCREEN
DOWN
Date
THD and Harmonics Screens
For models with THD, only current THD and voltage THD screens will be displayed.
For models with harmonics, separate harmonics for current and voltage can be displayed also.
BUTTON NAME
DISPLAYED MEASUREMENT SCREEN
UP
THD V
BUTTON NAME
DISPLAYED MEASUREMENT SCREEN
UP
VOLTAGE HARMONICS (H01, H02, ..., H51 in order) (Only for MPR47S model)
