1. Press the SET button while on Outputs menu.
2. Select the relevant output number and press the SET button to start the selection.
3. Select an output operation type mentioned above by using UP/DOWN buttons.
4. When exiting from the menu with the BACK or ESC button, don’t forget to save the changes.
Recording Settings
The following parameters can be recorded to the internal memory of the device in adjustable time
intervals. Afterwards, the recorded values can be remotely viewed:
1. Load Profile
2. Voltages
3. Currents
4. Powers
5. THD values
Selecting Parameter to Be Recorded
The parameter to be recorded to the internal memory is selected as following:
Load Profile Settings
1. Press the SET button while Log Setup-Load Profile is displayed.
2. Current option is displayed. Press the SET button again.
3. Select Active or Passive with UP/DOWN buttons. Press the SET button.
4. If you select Active option, recording time interval selection will be active.
5. Select you recording time interval in seconds with UP/DOWN buttons.
6. Finish the selection by pressing the SET button.
7. When exiting from the menu with the BACK or ESC button, don’t forget to save the changes.
