52
IP1967EN - 2016-08-01
Display Description
SO - Enabling reversal safety contact functionality.
When enabled (ON) with the automation idle, if the contact
1-8 is open, all operations are prevented.
When disabled (OFF) with the automation idle, if the con-
tact 1-8 is open, it is possible to activate the opening ope-
ration.
OFF ON
NI - Activation of NIO electronic anti-freeze system.
When enabled (ON), it maintains the efficiency of the mo-
tors even in low temperatures.
Note: for correct operation, the control panel must be ex-
posed to the same ambient temperature as the motors.
OFF ON
64 - Functioning of safety stop/closing command.
STOP CLOSING
P2 - Functioning of partial opening command contact 1-20.
P3 - Partial opening command.
1-2 - Enablement of automatic closing
PARTIAL
OPENING
AUTOMATIC
CLOSING
EO - Functioning of electric lock/electric brake.
SC - Functioning of electric lock (functioning time set
via adjustment )
SF - Functioning of electric magnet powered with au-
tomation closed
ELECTRIC
LOCK
ELECTRIC
MAGNET
FF - Setting function of 0-14 exit.
OF - Courtesy light
ON - Flashing light
COURTESY
LIGHT
FLASHING
LIGHT
WARNING: it is possible that, owing to the type of automation and control panel, certain
menus are not available.
i
