Maintenance And Service
cast DooR RemovaL:
Figure 22. Top latches for glass door (cast top and door removed)
Figure 23. Bottom Alignment Slot for glass door.
Door Latch Mechanisms
Alignment Slot
*Parts removed
for clarity*
In order to install the log set, and
for regular cleaning, the glass door
must be removed. The cabinet
front must rst be removed, as
outlined in the section above,
before accessing the door latches.
There are two (2) door latch
mechanisms on top the glass door
as shown in Figure 22. Each latch
can be pulled straight out and up
by hand. When the top latches are
unhooked, the door can be lifted
up out of the alignment slot at the
bottom of the rebox, shown in
Figure 23.
To replace the glass door, simply
reverse the above procedure.
Warning: Do not touch or attempt
to remove the glass door if the
replace is not completely cold.
WARNING: Never operate the
replace with the glass door
removed.
gLass DooR RemovaL:
16
Cast Top
Cast Door
The cast door on the Berkeley needs to be
removed whenever access to the rebox is
required. First the Berkeley must be turned
off and allowed to fully cool. Next, remove
the Cast Top as shown in Figure 21 by simply
lifting up. Lay the cat top down on a towel or
blanket to prevent scratching of the nish.
The cast door, with safety screen attached,
can now be removed be rst pulling the
bottom out then lifting up to unhook the
top. Lay the door face down on a towel or
blanket to prevent scratching of the nish.
To re-install the cast door simply reverse the
procedure.
Figure 21. Cast Door Removal
