aiR shutteRs:
Behind the valve access door is the air shutter adjustment levers on the right hand side of the venturi box
(see Figure 4) above the control panel. The air shutters allow the amount of air coming into the replace
to be adjusted in order to accommodate different climates and venting arrangements. The left shutter
adjusts the rear burner and the right shutter adjusts the front burner. Start the pilot and then the burner.
Make sure the pilot ame is burning normally and none of the burner ports are plugged. Let the replace
burn for roughly fteen minutes and then examine the ames, compare the ames to Figure 50.
The ideal ame will be blue at the base and light orange above. The ames should be of medium height.
If the ames look like this, no venturi adjustment is needed. If the ames are fairly short and mostly blue,
the replace is getting too much air. Therefore, the air shutter should be closed (pushed in) slightly until
the correct ames are achieved. Flames that are very orange, with tall, dark, stringy tips, are not getting
enough air. Open (pull out) the venturi until the ames clean up. If the shut is opened, or closed all the
way, and the correct ames cannot be attained, turn off the gas and contact the dealer.
Warning: Incorrect shutter adjustment may lead to improper combustion, which is a safety hazard.
Contact the dealer if there is any concern about the venturi adjustment.
Figure 4. Air shutter adjustment lever.
8
Less Air
More Air
Front Burner
Rear Burner
Operating Instructions
noRmaL sounDs DuRing opeRation:
Table 1: Normal Sounds
Component Sound & Reason
Berkeley Creaking when heating up or cooling down.
Burner Light pop or poof when turned off; this is more common with LP units.
Temperature Sensor Clinking when it senses to turn the blower on or off.
Pilot Flame Quiet whisper while the pilot ame in on.
Blower / Fan Air movement that increase and decreases with the speed of the blower. The
blower is pushing the heat from the replace into the room.
Gas Control Valve Dull click when turning on or off, this is the valve opening and closing.
Remote contRoL opeRations:
Proame 2 is a modular remote control system that directs the functions of the Berkeley. The Proame
2 TMFSLA is congured to control the on/off main burner operation, its ame levels and provides on/off
and Smart thermostatic control of the appliance. The system also controls the fan speed through six (6)
levels and can turn off the front burn independantly.
