Installation
5 Installation
5.1 Notes on safety for the installation
Aer carefully cleaning all around the area where the burn-
er will be installed, and arranging the correct lighting of the
environment, proceed with the installation operations.
All the installation, maintenance and disassembly
operations must be carried out with the electricity
supply disconnected.
The installation of the burner must be carried out
by qualied personnel, as indicated in this manual
and in compliance with the standards/regulations
and local authority legislation.
WARNING
DANGER
5.2 Handling
The handling operations for the burner can be
highly dangerous if not carried out with the great-
est attention: keep any unauthorised people at a
distance; check the integrity and suitableness of
the available means of handling.
Check also that the area in which you are working
is empty and that there is an adequate escape
area (i.e. a free, safe area to which you can
quickly move if the burner should fall).
Aer positioning the burner near the installation
point, correctly dispose of all residual packaging,
separating the various types of material.
Before proceeding with the installation opera-
tions, carefully clean all around the area where
the burner will be installed.
CAUTION
WARNING
5.3 Preliminary checks
Aer removing all the packaging, check the
integrity of the contents. In the event of doubt,
do not use the burner; contact the supplier.
The packaging elements (wooden cage or
card-board box, nails, clips, plastic bags, etc.)
must not be abandoned as they are potential
sources of danger and pollution. They should
be collected and disposed of in the appropriate
manner and location.
Checking the consignment
Checking the characteristics of the burner
The output of the burner must be within the
boiler’s ring rate.
A burner label that has been tampered with,
removed or is missing, along with anything else
that prevents the denite identication of the
burner makes any installation or maintenance
work dicult.
CAUTION
WARNING
WARNING
Part No
A
Type
B
Mode
C
Voltage
D
Phase
E
kg.hr Min
F
Max
G
Serial Number
H
Batch No
I
www.eogb.co.uk T 01480 477066
WARRANTY INVALID IF REMOVED
EOGB Energy Products Ltd
5 Howard Road, Eaton Socon, Cambs, PE19 8ET
Check the identication label of the
burner showing
A - Part number
B - Burner type
C - Burner Mode
D - Burner Voltage
E - Motor Phase
F & G - Minimum & maximum ow rate
H - Serial number
I - Batch number
Fig. 4
