Technical description of the burner
4 Technical description of the burner
4.1 Technical data
X400 X500 X600
Burner operation mode One Stage
Heat output
kW 14-36 34-62 50-80
Kg/hr 1.2-3 2.83-5.15 4.23-8.45
Working temperature °C min./max. 0-40
Weight (burner only) kg 8kg 8kg 9.3kg
Viscosity
Kerosene
Maximum viscosity 5.5 cst @ 20°C Suitable for bio blends < B10
Gas Oil
mm²/s (cSt)
4 - 6 (@ 20°C) for light oil models / 1.5 - 6 (@ 20°C) for kerosene
models
Pump
Type BFP11 L3 BFP11 L3 BFP11 L3
Pump Pressure range 7-15 bar (max . 10 bar @ 1.3 cSt, max 15 bar @ 1.8 cSt)
Factory setting 10 bar +/-1
Capacity 24 l/h
Fuel temperature Max °C 50
Fan Type Centrifugal, Counter clockwise
Air temperature Max °C 40
Electrical supply Ph/Hz/V 1/50/230 + / - 10%
Control box Type TF830.3 TF830.3 TF830.3
Protection level IP Rating IP30
Motor info
Wattage 90 90 130
Voltage 230 230 230
Ignition transformer
Type Danfoss EBI Danfoss EBI Danfoss EBI
Info 230v 0.25 A 60VA 40 mA (rms) 15kV 2 pole 33% ED in 3 min
Operation
Intermittent (at least one stop every 24 hours)
Start current (amps) 1.6 1.6 2.2
Run current (amps) 0.53 0.53 0.87
Sound pressure dB (A) 69 67 68
CO emission mg/kWh <30
Grade of smoke indicator N° Barcharach <1
Nox emission mg/kWh < 200
Directives
Machines Directive 98/37/EEC
Eciency Directive 92/42/EEC
Pressure Equipment Directive 97/23/EC
Low Voltage Directive 2014/35EU
EMC Directive 2015/30/EU
Conforming to EN 267 2009+A1:2011
Burner information
Fuel / Air Information
Electrical data
Emissions
Approval
Table. A
Reference conditions
Temperature 20 °C
Pressure 1013 mbar
Altitude 0 m a.s.l
Noise measured at a distance of 1 meter
