EOGB X500 - X500 Spare Parts List Details (Cont.)

37
Revision 1 01/01/16
Spare parts list
10.2 X500 Spare parts list
Item Part number Description
1 E80-0901 Fan 120mm x 52mm le hand rotation
2 E80-0702 Motor mounting ange
3
M02-1-90-19 Motor
M02-0004 Capacitor 4mF
M02-0012 3 Pin motor lead
4 C01-0005 Motor/pump coupling
5
D01-071N0156 BFP11 L3 Pump Bio 10
D01-071N0010 BFP 240v coil
D01-071G0202 3 Pin pump solenoid cable 280mm
E80-300-202-204-02 Brass manifold 70mm 1/8”m x 1/8”m for
pressure gauge
E80-300-999-000-00 1/8” port plug
6 E80-1401 Outer oil pipe - Pump to nozzle assembly
7 E80-0408 Air intake grill X400/500 (balanced)
8 E80-400-111-325-00 Bolt M6 x 24
9 E80-407-100-000-00 Spring
10
E80-0405 Air intake housing X400/500 (balanced ue)
E80-501-001-000-02 Acoustic bae X400/500 (balanced ue)
11a
E80-0010 Air damper (low output) + seal
11b E80-0007 Air damper (high output) + seal
12
E80-0402 Side cover X500/600
13
E80-500-005-120-00 Neoprene sponge sealing cord 650mm
required
14 E80-1301 Electronics cover X500
15 E80-302-006-112-01 5 pin terminal strip 32amp
16 E80-002-008-000-07 Control chassis X500/600
17 E80-1201 Inner assembly sliding bracket X500/600
18 S01-59101 Mounting ange for MZ photocell
19 E80-502-200-001-00 Grommet for inner assembly
20 S01-TF830.3 TF830.3 Control box
21 S01-70503 Cable entry plate for S98 base
22 S01-S98 S98 control box wiring base
23 X01-0048 Cable gland
24
D01-052F4031 EBI ignition transformer (includes mains
cable)
D01-052F0132 Mains lead for ignition unit 320mm
25 S01-MZ770S-2 MZ Photocell
26 E80-502-200-001-00 Grommet for ignition cables
27 E80-400-112-420-00 M8 x 20 steel zinc panhead slotted drive
28 E80-0203 Blast tube gasket 105 x 86 x 2mm
Item Part number Description
29
E80-0106 Blast tube EMB 87mm X500 Standard
E80-0107 Blast tube EMB 140mm
E80-004-003-021-00 Blast tube EMB 207mm
30 E80-0202 O ring - Blast tube to burner mounting
ange 89mm ID x 5mm
31 E80-0701 Burner mounting ange
32 E80-0201 Burner mounting gasket
33 E80-402-102-080-00 M8 steel zinc plated half nut
34 E80-400-143-416-00 M8 x 16 steel zinc plated c/sunk
35 E80-0601 Ignition cable 3mm angled x 3mm straight
(sold individually)
36
E80-0301 Electrode block X500/600
37
E80-300-802-102-00 Inner assembly including nozzle holder to
suit X500 87mm head (Standard)
E80-300-802-104-00 Inner assembly including nozzle holder to
suit X500 140mm head
E80-300-802-106-00 Inner assembly including nozzle holder to
suit X500 207mm head
38 E80-406-102-007-00 25mm x 18.5mm x 1.5mm spacer
39
Please note that the oil nozzle size should be determined by the
boiler/appliance manufacturer. If in doubt the please contact
EOGB for further information on nozzle sizing or refer to Table E
Page 21
40
E80-0502 Brake plate EMB type 87mm (includes elec-
trode block) Standard X500
E80-0501 Brake plate EMB type 140mm/207mm
(includes electrode block)
