EN-12 Installation and Operating Instructions - EOS Vision
Identification
EN
2.5 Technical data
All line cross-section specifications are the minimum cross-sections for the
copper line. The sauna heater must be operated by a sauna control unit.
*) Not required for Compact D18/H18 control units.
Heater output 9 kW 10 kW 12 kW 15 kW
Unit dimensions HxWxD in cm 95 x 60 x 60
For cabin volume 9–14 m³ 11–15 m³ 14–18 m³ 18–25 m³
Minimum size
Air inlets and outlets
35 x 6 cm 35 x 7 cm 35 x 9 cm
Weight without rocks
Vision: 89.5 kg
Vision Stone: 91 kg
Stone filling weight ~ 40 kg
Caliber
50–100 mm
Power extension unit No LSG 10*
Power connection 400 V 3N ~ 50 Hz
Connection mains – control unit 5 x 2.5 mm²
Connection control unit – heater
5 x 1.5 mm²
Connection mains – LSG -
5 x 2.5 mm²
Connection LSG – heater - 5 x 1.5 mm²
Connection control unit – LSG -
4 x 1.5 mm²
Leakage current
Max. 0.75 mA per kW heater output
Fuse protection for control unit 3 x 16 A
Fuse protection for LSG unit 3 x 16 A
