EOS Vision - Installation and Operating Instructions EN-19
Installation
3.1.3 Temperature sensor
It is essential that the temperature sensor with the safety temperature lim-
iter (STB) is installed.
The temperature sensor with the safety temperature limiter is not included
in the scope of delivery.
WARNING
Risk of fire due to incorrect temperature sensor position
Overheating can occur if the temperature sensor is installed in the
incorrect position; in this case, the sensor may read a lower tem-
perature than actually exists in the cabin.
This would trigger the sauna heater to continue to heat, even
though the desired temperature has already been reached.
Install the sensor as shown in the figure Dimensions in the
cabin, EN-16.
The temperature sensor must be installed where expected temperatures
are the highest, meaning above the heater.
For placement, see Dimensions in the cabin, EN-16.
NOTICE
Malfunction due to damaged temperature sensor
The temperature sensor is protected by its housing.
Ensure that the housing and the temperature sensor are not
damaged during operation.
