EOS Vision - Installation and Operating Instructions EN-21

Installation

 Setting up the base plate

1 Move the pallet with the heater and base plate as close to the pre-de-

fined installation site as possible.

2 Lift the base plate from the pallet and move it to the pre-defined instal-

lation site.

 If the heater is placed in front of the cabin wall, the opening in the

base of the base plate must face the cabin wall.

 Preparing the heater

1 Place an underlay on the floor in front of the base plate to protect the

floor and the heater from damage.

2 Lift the heater from the pallet and place it on the underlay in front of the

base plate.

 The rear side of the heater must face upward.
