EN-34 Installation and Operating Instructions - EOS Vision
Electrical installation
EN
12* and 15* kW heater output
Internal wiring 10, 12 and 15 kW (without LSG)
12 kW = 6x 2000 W
15 kW = 6x 2500 W
*) Only for connecting to Compact D18/H18 control units.
12** and 15** kW heater output (with LSG)
Internal wiring 12 and 15 kW (with LSG)
12 kW = 6x 2000 W
15 kW = 6x 2500 W
**) Not for connecting to Compact D18/H18 control units.
UVW
X YZ
NNN
PE
(Gr)
UVW
X YZ
NNN
PE
(Gr)
UVW
X YZ
NNN
PE
(Gr)
to
control unit
to
LSG
To Next Page
