Epec 5050 Technical Document

Technical Manual 5050 / MAN000539 Page 11/92
Epec Oy reserves all rights for improvements without prior notice
Epec Oy Postiosoite/Postal address Puhelin/Phone Fax Internet
Tiedekatu 6 PL/P.O.Box 194 +358-(0)20-7608 111 +358-(0)20-7608 110 www.epec.fi
FIN-60320 Seinäjoki FIN-60101 Seinäjoki, Finland
Communications/ Interfaces
4 x CAN 2.0 B,
1 x Ethernet
I/O pins total
65
Outputs
12 PWM/DO/DI with high side current measurement up to
2,5 A, PWM frequency adjustable by application
8 PWM/DO/DI with high side current measurement up to
2,5 A, voltage measurement, PWM frequency by application
4 PWM/DO/DI up to 2,5 A, PWM frequency by application,
pull-up / pull-down selection by application
4 PWM/DO/DI up to 4 A, PWM frequency by application,
pull-up / pull-down selection by application
4
DO/DI sinking up to 3 A
Inputs
11 DI/AI 0-10 V / 0-22 mA selection by application,
pull-up/ pull-down selection by application
12 bit AD converter
4 DI/PI 5/10 V, threshold selection by application,
pull-up/pull-down selection by application
14
DI/PI pull-up/pull-down selection by application
4
DI/PI pull-down to GND
