Technical Manual 5050 / MAN000539 Page 77/92
Epec Oy reserves all rights for improvements without prior notice
Epec Oy Postiosoite/Postal address Puhelin/Phone Fax Internet
Tiedekatu 6 PL/P.O.Box 194 +358-(0)20-7608 111 +358-(0)20-7608 110 www.epec.fi
FIN-60320 Seinäjoki FIN-60101 Seinäjoki, Finland
The following table shows some baud rates in general purpose CAN bus networks as well as
the maximum bus length for a given baud rate, that CAN in Automation (CiA) international users
and manufacturers group has recommended to be used. For more information, refer to CiA DS-
102 standard.
CAN bus baud rates and bus lengths according to CiA DS-102 standard
Baudrate Bus length
1 Mbits/s
25 m
800 kbits/s
50 m
500 kbits/s
100 m
250 kbits/s
250 m
125 kbits/s
500 m
50 kbits/s
1000 m
20 kbits/s
2500 m
10 kbits/s
5000 m
8.4.2 CAN Bus
The CAN bus cable is the neural backbone of the whole system and should be designed and
constructed with extra care.
In all Epec 5050 control units, the bus connections can be found in grey AMP 35 pin
connector (connector1).
5050 control unit's CAN1 is equipped with double pins that enables cabling without
branching the wire harness
For information about the CAN bus lengths and baud rates, refer to section
System
Topologies.
Cable
It is recommended to use high quality and twisted (approx. 1 round/ 1 inch) CAN bus cable.
Normal UTP (Unshielded Twisted Pairs) cable is well suited for distances under
approximately 10 meters.
In longer distances, and especially if there is possibility for electromagnetic interference, it
is highly recommended to use shielded and twisted cable for CAN bus, also for shorter
distances.
To avoid electromagnetic interference (EMI), locate the bus cable as far away from high-
current carrying cables as possible. Generally, the amount of the connections and
connectors should be minimized to maximize security; also all connections should be done
carefully.
The shield grounding must be done only in one end of the cable
