8.7 Accessories and Ordering Codes
Related products
Product Epec ordering code Epec data sheet code
Measuring adapter
E3003510
MAN000512
CAN adapter
E3003509
MAN000513
AMPSEAL Connectors
Epec uses gold plated, locked and sealed AMPSEAL heavy duty connectors for all Epec CAN
Module Family products to ensure endurance under extreme conditions.
• All connectors are mechanically keyed to mate only with identical colors
AMPSEAL product TE Connectivity
ordering code
Epec ordering code
AMP 35 pin grey plug (female)
776164-4
KX0351
AMP 35 pin blue plug (female)
776164-5
KX0352
AMP 35 pin black plug (female)
776164-1
KX0353
Contact for AMP plug assembly
770854-3
KX0010
Crimping tool
58529-1
TT0018
Wire relief for a connector
776463-1
KX0354
AMPSEAL cable dimensions
Size
Insulation
diameter range
Strip length ±0,4
mm² AWG
0,5
20
1,7
to
2,7
5,1
0,8
18
1,4
16
1,5 ---
2,2
to
2,4
Typical hand crimping tool e.g.: AMP Procrimper 58529-1 (TE Connectivity), Epec ordering
code TT0018
