Calculated
C
I
Input pin capacitance
typ. 1
nF
V
I-max
Max Input voltage
Overload conditions (Note
3)
-5 50 V
Note 1: Temperature-dependent.
Note 2: Referenced to GND.
Note 3: Exceeding the max value might cause damage to input.
Functional block diagram
Other Information
Refer to section Connection Examples to see examples of how to connect external
actuators or sensors when using this type of pin.
