X1.32 PWM/DO/DI
Power 1 2A
X1.33 PWM/DO/DI
Power 1 4A
X1.34 PWM/DO/DI
Power 1 4A
X1.35 PWM/DO/DI
Power 1 4A
X2.13 PWM/DO/DI/CM
Power 1 2A
X2.14 PWM/DO/DI/CM
Power 1 2A
X2.26 DO_GND
Power 1 3A
X2.27 DO_GND
Power 1 3A
X2.34 DO_GND
Power 1 3A
X2.35 DO_GND
Power 1 3A
X2.28 PWM/DO/DI/CM
Power 2 2A
X2.29 PWM/DO/DI/CM
Power 2 2A
X2.30 PWM/DO/DI/CM
Power 2 2A
X2.31 PWM/DO/DI/CM
Power 2 2A
X2.32 PWM/DO/DI/CM
Power 2 2A
X2.33 PWM/DO/DI/CM
Power 2 2A
X3.26 PWM/DO/DI/CM
Power 2 2A
X3.27 PWM/DO/DI/CM
Power 2 2A
X3.28 PWM/DO/DI/CM
Power 2 2A
X3.29 PWM/DO/DI/CM
Power 2 2A
X3.30 PWM/DO/DI/CM
Power 2 2A
X3.31 PWM/DO/DI/CM
Power 2 2A
X3.32 PWM/DO/DI/CM
Power 2 2A
X3.33 PWM/DO/DI/CM
Power 2 2A
X3.34 PWM/DO/DI/CM
Power 2 2A
X3.35 PWM/DO/DI/CM
Power 2 2A
Connector pin
number
Current / Pin Note
X2.3
10 A
The maximum sum of GND pin currents cannot exceed
28 A.
X2.10
10 A
X2.11
10 A
X2.12
10 A
X3.3
10 A
X3.4
10 A
