CAN - CANopen Interface
Installation guide
Pin
Signal
Description
1
CAN_H
CAN high bus
2
CAN_L
CAN low bus
3
GND
GND
4
-
No connection
5
-
No connection
6
-
No connection
7
-
No connection
8
VCC
5V supply from EPC
If the installation has more than one EPC external interface module, this cable should
be connected to CONNECTOR
of the upwards interface.
This cable can be provided by epic power (see 4.2), contact with sales@epicpower.es for
its purchase.
2) CONNECTOR 2:
CAN Bypass connector
This is a CAN Bus bypass connector used where multiple interfaces are available at the
installation to create a daisy-chain. In this case, the cable should be connected to the
CONNECTOR of the downwards interface by a RJ-45 cable, category CAT5e or
higher, whose maximum length is 100 meters.
In case that there are no more interfaces, or this is the last one of the daisy chain, a
termination resistor must be installed. A terminator (see 4.4) can be purchased to epic
power by contacting with sales@epicpower.es.
The pinout of this connector is the same as CONNECTOR
(See Fig. 3).
1
2
1
