CAN - CANopen Interface
Installation guide
4. EXTERNAL DESCRIPTION
4 2 1
3
5
Fig. 2 CAN - CANopen interface top and bottom view
1) CONNECTOR 1:
EPC communication cable connector
This connector is used to communicate the DC/DC converter (EPC) and the CAN -
CANopen interface. It is a standard RJ-45 socket and its pinout can be seen in Fig. 3.
Fig. 3 Connector 1 Pinout
