SmartROC T35/T40 9 Feed Unit
39 No: 7026962571.1.7027002891 en-US
3.
Remove the slide pieces (C) from the holder.
4.
Slide a new slide piece into the holder track and install it to the holder.
5.
Install new keys.
6.
Adjust the cradle on the feed beam.
Adjusting Cradle on Feed Beam
WARNING
Disassembling and Assembling Components
Can cause personal injury.
u Components that could move or fall down must be securely supported or strapped in
place during service and maintenance work.
WARNING
Heavy Objects
Can cause crushing injury or death.
u Do not stand under the heavy object being lifted.
u Use adequate lifting equipment.
WARNING
Moving Parts
Can cause personal injury.
u Shut off the machine and lock the battery isolation switch before starting any work.
u Make sure that the hydraulic pump is off and that the system is depressurized before
starting work.
The cradle plates for the rock drill, intermediate drill rod support, and water hose drum are
guided along the feed beam by holder (A). Each pair of holders is locked in position with
bolts (B). The bolt holes in the holders are in the form of angled grooves. The cradle can
be adjusted on the feed beam by shifting the holders lengthways.
