1 Automatic Document Feeder (ADF) cover

2 ADF input tray

3 ADF edge guide

4 ADF output tray

1 Rear paper feeder

2 Paper support

3 Edge guide

4 Output tray cover

5 Output tray

6 Stopper

Parent topic: Product Parts Locations
